Not the best or the most beautiful appliance around and not the pedal too, but I'm quite happy I've finished it, together with the enclosure. Aiken Reactive Dummy Load https://www.thegearpage.net/board/index.php?threads/aikens-reactive-dummy-load.1072793/, made using this schematic:



I also made smaller inductor myself (470uH), and the bigger one is made by P&K Audio from Belgrade - famous amp builder, but he also makes transformers for other people. Couldn't find 200uF bipolar cap locally, so I bought two 390uF and put them in series. Still have to test the unit.











« Last Edit: February 03, 2021, 12:00:27 PM by rankot »
  • SUPPORTER
50 pedals and counting!

davent

Re: Pictures!
« Reply #29201 on: February 03, 2021, 12:27:27 PM »
That came out really well, looks good!
dave
"If you always do what you always did- you always get what you always got." - Unknown
https://chrome.google.com/webstore/detail/photobucket-hotlink-fix/kegnjbncdcliihbemealioapbifiaedg

rankot

Re: Pictures!
« Reply #29202 on: February 03, 2021, 12:37:27 PM »
That came out really well, looks good!
dave
Thanks! Drilling aluminum was really a PITA, I broke three 2mm bits during process. Finally bought 2.5mm one and that one finished the job.
  • SUPPORTER
50 pedals and counting!

garcho

Re: Pictures!
« Reply #29203 on: February 03, 2021, 07:40:34 PM »
bravo, nice work Ranko!
  • SUPPORTER
"...and weird on top!"

rankot

Re: Pictures!
« Reply #29204 on: February 05, 2021, 04:05:23 PM »
One more - this time it IS a pedal, actually Harmonic Percolator - but renamed to Horn Grower, since this is a birthday present for our young family friend (aged 12), who really likes to show horns! Artwork is done by my daughter :)





I wanted to put this into 1590A, but then, after building it, noticed that PCB will collide with jacks, so it got bigger enclosure.
« Last Edit: February 05, 2021, 04:07:09 PM by rankot »
  • SUPPORTER
50 pedals and counting!

temol

Re: Pictures!
« Reply #29205 on: February 05, 2021, 04:22:41 PM »
Quote from: rankot
One more - this time it IS a pedal, actually Harmonic Percolator

Nice! I like spaghetti-looking tracks :)


andy-h-h

Re: Pictures!
« Reply #29206 on: February 05, 2021, 05:02:43 PM »
D*A*M Red Rooster Germanium Booster

Sounds great, I'm pretty happy with the end result - far from perfect, but works for me.  :icon_wink:




rankot

Re: Pictures!
« Reply #29207 on: February 05, 2021, 05:10:07 PM »
Quote from: rankot
One more - this time it IS a pedal, actually Harmonic Percolator

Nice! I like spaghetti-looking tracks :)

Spaghetti everywhere!

 ;D
  • SUPPORTER
50 pedals and counting!

Phend

Re: Pictures!
« Reply #29208 on: February 16, 2021, 11:13:49 AM »
Little Jim:
Finally after replacing the tube in my laser, I was able to cut the wood for the box.
And assemble the components "inside the box".  It sounds fantastic. No hiss (I don't miss).
Matched the BS170's using cheap meter. Matched the 4k7 resistors on either side of them.
Added a 330 ohm switched resistor at C3. And a B10k pot for fart suppression.
Used my patented special battery clip and 14ga wire where the current might exceed 12 amps.

Here are the pictures...Thanks Jonny.Reckless and the rest for your discussion on Little Jim.








  • SUPPORTER
Making decisions quickly like a squirrel on the highway

Marcos - Munky

Re: Pictures!
« Reply #29209 on: February 16, 2021, 02:00:54 PM »
Very beautiful build, again. Another artwork you made.

14ga wire where the current might exceed 12 amps.
I'd really worry about if any stompbox current exceed 12 amps  :icon_lol:

amptramp

Re: Pictures!
« Reply #29210 on: February 17, 2021, 06:44:20 AM »
Are you actually gigging with something that is still in breadboard form?  You've got more guts than me.

Phend

Re: Pictures!
« Reply #29211 on: February 17, 2021, 07:20:29 AM »
^ No, for home use only. You should never take a bread box to a gig unless you bring cheeze or Peanut butter.
« Last Edit: February 17, 2021, 07:25:09 AM by Phend »
  • SUPPORTER
Making decisions quickly like a squirrel on the highway

kaycee

Re: Pictures!
« Reply #29212 on: February 18, 2021, 04:42:17 PM »
A second, and final Hudson Broadcast for myself - other one was a present to my step son.




mtk

Re: Pictures!
« Reply #29213 on: February 18, 2021, 05:31:49 PM »
A second, and final Hudson Broadcast for myself - other one was a present to my step son.





That looks badass. Great work.

BarbarachBC

Re: Pictures!
« Reply #29214 on: February 23, 2021, 09:12:56 AM »
LPB-1 clone, and me playing with ink markers for the design.








vigilante397

Re: Pictures!
« Reply #29216 on: February 25, 2021, 04:11:05 PM »
New one from me, this is a 12AU7 buffer in a 1590B, unity gain so no controls, probably doesn't even need a footswitch :P Finish is UV print with sparkly clear powdercoat over the top.





Obligatory guts

« Last Edit: February 25, 2021, 04:15:50 PM by vigilante397 »
  • SUPPORTER
"I'm not sure what "serious design flaws" you see. Does it explode or poison your dog?" - PRR

www.sushiboxfx.com

temol

Re: Pictures!
« Reply #29217 on: February 27, 2021, 04:57:24 AM »
Korg CX3 rotary effect. Laser engraved faceplate, walnut side panels.




Phend

Re: Pictures!
« Reply #29218 on: February 27, 2021, 12:26:28 PM »
Hello all:
Started on my next project. It is kind of an R & D prototype.
I am posting this so you can see the main parts unassembled.
It is a simple GGG EXH Muff Fuzz Transistor Version. Non gig version. Home use only.
I added an LED with capacitor and Tone control that I learned from building Little Jim.
This is not your ordinary build.
I havenít looked thru all 1461 pages of the Pictures to see any other unordinary builds.
The blue fluorescent acrylic box is quite sturdy, albeit I wonít be stomping on it, but could.
I also built my first circuit board. Ok you can start chuckling now.
Will be using LED's for a different type of expression.
Paul (stay tuned)






  • SUPPORTER
Making decisions quickly like a squirrel on the highway

ElectricDruid

Re: Pictures!
« Reply #29219 on: February 27, 2021, 12:43:16 PM »
Korg CX3 rotary effect. Laser engraved faceplate, walnut side panels.

Beautiful, Temol! And quite synthy too, with the wooden end panels!

Can you give us a quick overview of how the old Korg CX3 does its rotary effect? I'm imagining "drum" and "rotor" chorus circuits operating at different rates or some such? Is it anything like that? How did they do the ramping form Slow to Fast?
